Specifications
Zigzag stitch capability up to 5mm.
Portable, making it easy to carry and use.
Undergoes a rigorous 10-point reliability check.
Sews up to 8 layers of Sunbrella Plus fabric.
Features a built-in speed reducer.
Equipped with a heavy-duty carrying handle.
Full Accessory Kit Included
Operation
RPM 800
Stitch Length 0 - 6mm
Stitch Width 0 - 5mm
Needle System # 135 x 17
Work Space 7" / 17.8cm
Weight 34 lbs / 15.4kg
Warranty Limited 3 year
Electrical 110V / 120V 60 Hz
Specifications
Zigzag stitch capability up to 5mm.
Portable, making it easy to carry and use.
Undergoes a rigorous 10-point reliability check.
Sews up to 8 layers of Sunbrella Plus fabric.
Features a built-in speed reducer.
Equipped with a heavy-duty carrying handle.
Full Accessory Kit Included
Operation
RPM 800
Stitch Length 0 - 6mm
Stitch Width 0 - 5mm
Needle System # 135 x 17
Work Space 7" / 17.8cm
Weight 34 lbs / 15.4kg
Warranty Limited 3 year
Electrical 110V / 120V 60 Hz
Find the answers to your questions about the 2620ZW
What type of needles does the 2620ZW take?
135x17 from size 16-23. 135x16 for leather.
What bobbin does the 2620ZW take?
The largeType ‘M’ Bobbin. Reliable part #1CON18034 is used for the2620ZW.
Can I sew leather with the 2620ZW?
Yes, the 2620ZW is well-suited for all types of canvas, leather and synthetics of medium to heavyweight.
How fast does the 2620ZW sew?
The 2620ZW is rated at a top speed of up to 2,000 RPM.
What is the maximum stitch length?
The 2620ZW will sew a stitch of up to 6mm in length.
Will I have to oil the 2620ZW?
The 2620ZW is a direct drive sewing machine. The machine will oil itself, but there are a few spots marked on the head for manual oiling.
What does direct drive mean and what are the benefits?
Direct drive technology eliminates the need for an under-table motor and instead mounts a highly efficient motor directly to the shaft of the machine. This allows for more torque (power), smoother and quieter operation, and eliminates the need for the belt which traditionally connects the motor to the sewing head.
What comes with the 2620ZW?
Your Reliable sewing machine is supplied with our top-level heavy-duty 'I' type adjustable stand, a 55cm x 120cm tabletop with a special surface that resists cracking, and a drawer to store your accessories.
Does the 2620ZW come with a light?
Yes, the 2620ZW comes with our famous UberLight™ Flex light that provides a much broader light for your work and has brightness and color temperature adjustments as well.
How do I buy needles, supplies, and accessories for the 2620ZW?
For the fastest service, please visit our website to order the #135x17 or #135x16 needles in the size you require. For other items for the 2620ZW, we invite you to call 1-800-268-1649 and speak to one of our parts team members.
Does the 2620ZW require assembly?
When you receive your 2620ZW, you are just a few minutes away from sewing. Simply remove the fully assembled machine from the pallet. Attach the thread stand and oil the head according to the instructions provided in the manual. Plug it in and away you go. From unpacking the pallet to sewing in less than 10 minutes.
What is the warranty on the 2620ZW?
Reliable warranties the 2620ZW to be free of defects for one year.
